Waterproof M23 Power Connectors 12 Pin 23mm EMC Shielding IP67 4-9 Contact

waterproof M23 Connectors 23mm Panel opening size Screw locked EMC shielding IP67 4 - 9 contacts

Here's a comprehensive overview of M23 series connectors with a 23mm panel opening size, screw locking, EMC shielding, IP67 waterproof rating, and 4-9 contacts:

M23 Connectors Overview

Key Features:

1. Panel Opening Size: 23mm
2. Locking Mechanism: Screw locking for secure and reliable connections.
3. EMC Shielding: Designed to prevent electromagnetic interference, ensuring signal integrity.
4. Waterproof Rating: IP67, providing protection against dust and temporary immersion in water.
5. Contact Options: Available with 4 to 9 contacts, suitable for various signal and power transmission needs.

Applications:

• Industrial Automation: Widely used for connecting motors, sensors, and other devices in factory automation systems.
• Robotics: Ideal for connecting various components in robotic systems where secure and shielded connections are essential.
• Process Control: Suitable for environments requiring reliable and robust connections for process control equipment.
• Heavy Machinery: Used in applications where durable and waterproof connections are necessary.

Technical Specifications:

• Contact Material: Typically gold-plated brass or bronze for excellent conductivity and corrosion resistance.
• Housing Material: Often made of high-grade plastic or metal for durability and protection.
• Temperature Range: Usually operates within a wide temperature range, typically -40°C to +125°C.
• Voltage and Current Rating: Suitable for medium to high voltage and current ratings, making them ideal for both signal and power applications.

Examples of Products:

• Binder M23 Connectors: Binder offers a wide range of M23 connectors with various contact configurations, screw locking, EMC shielding, and IP67 ratings.
• Phoenix Contact M23 Connectors: Known for their reliability and robustness, Phoenix Contact provides M23 connectors suitable for industrial environments.
• TE Connectivity Intercontec Series: TE Connectivity offers M23 connectors with excellent EMC shielding and IP67 protection, ideal for demanding applications.
• Amphenol Tuchel M23 Connectors: Amphenol provides high-quality M23 connectors with various pin configurations and IP67 rating.

Installation and Usage:

• Mounting: The 23mm panel opening allows for easy integration into control panels or machinery.
• Connection: Screw locking mechanism ensures the connectors stay securely in place, even in environments with vibrations or mechanical stress.
• Maintenance: The IP67 rating ensures that the connectors can withstand dust and temporary water immersion, making them suitable for outdoor or harsh environments.

Specific Models and Manufacturers:

• Binder 823 Series: Available with 4 to 9 contacts, providing secure connections for signal and power.
• Phoenix Contact PLUSCON Circular M23: Offers M23 connectors with IP67 rating, EMC shielding, and a variety of pin configurations.
• TE Connectivity Intercontec M23 Series: Provides robust and reliable M23 connectors with screw locking and IP67 rating.
• Amphenol Tuchel M23 Series: Known for high-quality connectors, Amphenol provides M23 connectors with various pin configurations and IP67 rating.

These M23 connectors are designed to meet the needs of applications requiring secure, shielded, and waterproof connections.
