Designing connectors for new energy systems in automotive battery storage involves creating robust, high-performance connectors that can handle the demanding requirements of electric vehicles (EVs) and energy storage systems (ESS). Here's an approach to designing these connectors:

Key Components and Materials

1. Connector Housing:

   • Material: Use high-temperature-resistant plastics, such as PBT (Polybutylene Terephthalate) or PA66 (Polyamide 66), reinforced with fiberglass for added strength and durability.
   • Flame Retardancy: The housing should be flame-retardant, complying with standards like UL94 V-0, ensuring safety in the event of electrical faults.
   • Insulation: Ensure high electrical insulation properties to prevent short circuits and ensure safety in high-voltage applications.

2. Contacts:

   • Material: Use copper or copper alloys with high conductivity, plated with silver or gold to enhance corrosion resistance and conductivity.
   • Current Rating: Design the contacts to handle high currents typical of automotive battery systems, ensuring low contact resistance to minimize energy loss.
   • Durability: Contacts should be designed for high mating cycles, with robust spring mechanisms to maintain consistent contact pressure over time.

3. Sealing:

   • IP Rating: Aim for at least an IP67 rating to ensure the connectors are dust-tight and waterproof, suitable for use in the harsh environments of automotive applications.
   • Gaskets: Use silicone or EPDM (Ethylene Propylene Diene Monomer) gaskets to seal the connectors and prevent ingress of water, dust, and other contaminants.

4. Thermal Management:

   • Heat Dissipation: Incorporate design features that aid in heat dissipation, such as fins or thermal conductive materials, to manage the heat generated by high currents.
   • Temperature Resistance: Ensure all materials can withstand the temperature fluctuations common in automotive environments, from extreme cold to high heat.

Design Considerations

1. High Voltage and Current Handling:

   • Voltage Rating: Design connectors to handle the high voltages typically used in EV batteries (e.g., 400V to 800V).
   • Current Handling: Ensure the connectors can handle the high currents required by automotive powertrains, potentially exceeding 200A.

2. Safety Features:

   • Touch-Proof Design: Implement touch-proof designs to protect against accidental contact with live parts, ensuring safety during handling and maintenance.
   • Locking Mechanisms: Use secure locking mechanisms to prevent accidental disconnection, which could be catastrophic in high-power applications.
   • Polarization: Design the connectors to be polarized, ensuring that they can only be connected in the correct orientation, preventing reverse polarity.

3. Vibration and Shock Resistance:

   • Rugged Design: The connectors should be designed to withstand the vibration and shock common in automotive environments, ensuring reliable performance over the vehicle's lifetime.
   • Strain Relief: Incorporate strain relief features to prevent damage to the cables and contacts due to mechanical stress.

4. Ease of Use:

   • Quick Connect/Disconnect: Design connectors for easy and quick mating and demating, which is crucial for efficient assembly and maintenance in automotive production.
   • Ergonomics: Consider the ergonomics of handling the connectors, especially in confined spaces typical of automotive battery compartments.

Manufacturing Process

1. Prototyping:

   • Develop prototypes to test electrical, mechanical, and thermal performance. Prototyping allows for optimization of the design before moving to mass production.

2. Assembly:

   • Precision Molding: Use precision injection molding for the connector housing to ensure consistent quality and dimensional accuracy.
   • Contact Assembly: Assemble the contacts with care to ensure secure connections and consistent contact pressure.

3. Testing:

   • Electrical Testing: Conduct tests to verify current handling, voltage rating, and insulation resistance. Ensure the connectors perform reliably under load.
   • Environmental Testing: Test the connectors for resistance to water, dust, vibration, and temperature extremes, ensuring they meet automotive standards like ISO 16750.
   • Mechanical Testing: Evaluate the connectors' durability under repeated mating cycles, ensuring they maintain performance over time.

4. Quality Control:

   • Implement stringent quality control processes to ensure that each connector meets the required specifications for automotive applications.

Applications

• Electric Vehicle (EV) Battery Packs: Connectors used for high-power connections between battery modules, power electronics, and charging systems.
• Energy Storage Systems (ESS): Connectors for stationary battery systems used for energy storage, where high power and reliable connections are critical.
• Power Distribution: Connectors used in the distribution of power within EVs, connecting different high-voltage components.

Conclusion

Connectors for automotive battery storage in new energy systems must be designed with high voltage and current handling capabilities, robust safety features, and environmental durability. By focusing on these key areas, you can create connectors that meet the demanding requirements of modern electric vehicles and energy storage systems, ensuring safety, reliability, and performance.
