F Series High Density IP68 Waterproof Push Pull Connector with EMC Shielding and Fischer Compatibility

Place of Origin: China
Brand Name: BEXKOM
Certification: UL/CE/ROHS/REACH/ISO9001/ISO13485/MSDS/COC
Model Number: BK-U-XXX/BK-F-XXX
Minimum Order Quantity: 5pcs
Price: USD6.9~29.9/pc
Standard Packaging: PE bag + Carton Box
Delivery Time: 7 ~15 days
Payment Terms: L/C,T/T
Supply Ability: 100000pairs/month
Product Attachments

Product Details

Highlight:

IP68 Waterpoof circular push pull connectors

,

sF12 circular push pull connectors

,

Waterpoof sf12 connector
Shell Material: Brass Chrome Plated
Insulator Material: PPS/PEEK
Contact Material: Brass Gold Plated
Mating Cycle: >5000
IP Rate: IP68
Vibration: 10~2000Hz, 15g
Shock: 100g/6ms
Salt Spray Corrosion Resistance: 96 Hours
Color: Black And Sliver
Used In: MIL, Outdoor, Testing, Instrument
Product Description
F Series 2~37 Pins High Density IP68 Waterproof Push Pull Connectors with EMC Shielding
Technical Specifications
Series Name F Series
Pin Numbers 2 ~ 37
Shell Material Brass Chrome Plated
Pin Material Brass Gold Plated
Insulator Material PPS/PEEK
Waterproof Level IP68
Work Temperature -55°C to 250°C
Salt Spray Corrosion Resistance 96 Hours
Mating Cycles >5000 times
Current Rate 1.5 - 25 A
Testing Voltage 350 - 1000V
EMC Shielding Available
Locking Method Push Pull Locking
Shock Resistance 100g/6ms
Vibration Resistance 10~2000Hz, 15g
Key Features
  • Miniature Size: Compact design ideal for space-constrained applications including portable devices, wearable technology, and densely packed equipment.
  • Metal Shell: Brass chrome plated construction provides:
    • Enhanced durability and mechanical stress resistance
    • Superior EMI (Electromagnetic Interference) shielding
    • Improved heat dissipation compared to plastic alternatives
    • Extended lifespan in harsh environments
  • High Density: Accommodates large number of contacts in small form factor, enabling equipment miniaturization with multiple signal or power lines.
  • IP68 Waterproof: Complete protection against dust ingress and long-term water immersion beyond 1 meter depth for harsh environment applications.
  • EMC Shielding: Maintains signal integrity by preventing electromagnetic interference from external sources and containing EMI generated by connected equipment.
  • Circular Design: Provides easy alignment and mating, secure connections, and multiple contacts in compact form factor.
  • Gold Plated Contacts: Brass gold plated pins offer excellent conductivity, corrosion resistance, low contact resistance, and superior performance in low-voltage applications.
Applications
  • Aerospace and defense equipment
  • Industrial automation and control systems
  • Medical devices
  • Underwater sensors and equipment
  • Portable electronic devices
  • Automotive electronics
  • Test and measurement equipment

These connectors deliver reliable, high-performance connections in challenging environments where space constraints, environmental protection, and signal integrity are critical requirements.
