EMC Shielding 12mm M12 5pin Connector Bulkhead 3 - 17 Contacts

EMC shielding 12mm Panel opening size Screw locked IP67 waterproof M12 Connectors 3 - 17 contacts

Here is a comprehensive overview of M12 connectors with a 12mm panel opening size, screw locking, EMC shielding, IP67 waterproof rating, and 3-17 contacts:

M12 Connectors Overview

Key Features:

1. Panel Opening Size: 12mm
2. Locking Mechanism: Screw locking for secure and reliable connections.
3. EMC Shielding: Designed to prevent electromagnetic interference, ensuring signal integrity.
4. Waterproof Rating: IP67, providing protection against dust and temporary immersion in water.
5. Contact Options: Available with 3 to 17 contacts, suitable for various signal and power transmission needs.

Applications:

• Industrial Automation: Widely used for connecting sensors, actuators, and other devices in factory automation systems.
• Process Control: Ideal for environments requiring reliable and robust connections for process control equipment.
• Robotics: Suitable for connecting various components in robotic systems where secure and shielded connections are essential.
• Communication Systems: Used in networking and communication systems for data transmission.

Technical Specifications:

• Contact Material: Typically gold-plated brass or bronze for excellent conductivity and corrosion resistance.
• Housing Material: Often made of high-grade plastic or metal for durability and protection.
• Temperature Range: Usually operates within a wide temperature range, typically -25°C to +85°C.
• Voltage and Current Rating: Suitable for low to medium voltage and current ratings, making them ideal for signal and power applications.

Examples of Products:

• Binder M12 Connectors: Binder offers a wide range of M12 connectors with various contact configurations, screw locking, EMC shielding, and IP67 ratings.
• Phoenix Contact M12 Connectors: Known for their reliability and robustness, Phoenix Contact provides M12 connectors suitable for industrial environments.
• TE Connectivity M12 Connectors: TE Connectivity offers M12 connectors with excellent EMC shielding and IP67 protection, ideal for demanding applications.
• Murrelektronik M12 Connectors: Known for their high-quality industrial connectors, including those with IP67 ratings and various pin configurations.

Installation and Usage:

• Mounting: The 12mm panel opening allows for easy integration into control panels or machinery.
• Connection: Screw locking mechanism ensures the connectors stay securely in place, even in environments with vibrations or mechanical stress.
• Maintenance: The IP67 rating ensures that the connectors can withstand dust and temporary water immersion, making them suitable for outdoor or harsh environments.

Specific Models and Manufacturers:

• Binder 763 Series: Available with 3 to 17 contacts, providing secure connections for signal and power.
• Phoenix Contact SACC Series: Offers M12 connectors with IP67 rating, EMC shielding, and a variety of pin configurations.
• TE Connectivity M12 Series: Provides robust and reliable M12 connectors with screw locking and IP67 rating.
• Murrelektronik M12 Connectors: Available with various pin configurations, providing excellent protection and reliability in industrial applications.

These M12 connectors are designed to meet the needs of applications requiring secure, shielded, and waterproof connections. If you need more detailed information on specific models, datasheets, or manufacturers
